RCF ART 712-A MK5 ACTIVE TWO-WAY SPEAKER

Calculate Shipping

Description

Features

129 dB Max SPL
1400 WATT 2-way peak power
90° x 60°, Wide dispersion constant directivity horn
Innovative DSP Processing
1,75" Compression Driver
12" Woofer
FiRPHASE Technology
XBOOST Low Frequencies Enhancer

ART 712-A MK5 is a unique product in its category. The 1.75" compression driver offers unique vocal clarity and sound projection. The 12” woofer offers an extremely linear response and a precise, deep low frequency control. The transducers are produced using the most advanced assembly technologies. The amplifier delivers 1400 watts and is controlled by a DSP that takes care of crossover, equalisation, phase control, soft limiting and speaker protections.

Specifications

Acoustical Specifications

Frequency Response: 50 Hz ÷ 20000 Hz
Max SPL @ 1m: 129 dB
Horizontal Coverage Angle: 90°
Vertical Coverage Angle: 60°

Transducers

Compression Driver: 1 x 1.0'', 1.75'' v.c
Woofer: 1 x 12'', 2.5'' v.c

Input/Output Section

Input Signal: Balanced/Unbalanced
Input Connectors: XLR, Jack
Output Connectors: XLR
Input Sensitivity: -2 dBu/+4 dBu
Mic. Input Sensitivity: -32 dBu

Processor Section

Crossover Frequencies: 1600 Hz
Protections: Thermal, RMS
Limiter: Soft Limiter
Controls: Volume, Boost, MIC/Line

Power Section

Total Power: 1400 W Peak
High Frequencies: 400 W Peak
Low Frequencies: 1000 W Peak
Cooling: Convection
Connections: VDE

Standard Compliance

Safety Agency: CE compliant

Physical Specifications

Cabinet/Case Material: PP Composite
Hardware: 2 x M10
Handles: 1 on top, 1 each side
Pole Mount/Cap: 35 mm insert
Grille: Steel
Color: Black
Size:
- Height: 637 mm / 25.08 inches
- Width: 387 mm / 15.24 inches
- Depth: 363 mm / 14.29 inches
Weight: 17.8 kg / 39.24 lbs
