Chauvet DJ Freedom Wedge Quad Wireless Quad LED Par

The Chauvet DJ Freedom Wedge Quad, like the rest of the Freedom range, a 100% TRUE wireless, battery-operated LED Par. Complete with onboard D-Fi transceivers for sending and receiving DMX signals. Harnessing all that power into a triangularly shaped quad-colour LED wash light. Perfect for fitting inside triangular truss systems.

What’s more, the Freedom Wedge Quad also has a built-in adjustable leg. Allowing you to shine the light exactly where you need it. You can even attach your light to 35mm truss without having to use brackets thanks to the M10 and M12 threaded rig points.

Additionally, by using the built-in digital display, the Freedom Wedge Quad gives you the ability to create any colour without DMX. Alternatively, you can easily control static colours and automated programs by using the included IRC-6 remote. Finally, the Freedom Wedge Quad features built-in dimming curves for smooth dimming. While it’s flicker-free output is perfect for any on-camera and video use.

For even more power, the Freedom Wedge Quad allows you to link up to other LED fixtures for coordinated light shows!

DMX Channels: 4, 6, 10

DMX Connectors: 3-pin XLR

Light Source: 3 LEDs (quad-color RGBA) 6 W, (2.4 A), 50,000 hours life expectancy

Strobe Rate: 0 to 25 Hz

PWM Frequency: 1.2 KHz

Beam Angle: 19°

Field Angle: 36°

Maximum Run Time: (all on): up to 8 hours
(single color): up to 20 hours

Recharge Time: 5 hours

Operating Frequency: 2.412 to 2.484 GHz

Illuminance: 1,144 lux @ 2 m

Power Linking: 21 units @ 120 V; 39 units @ 230 V

Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)

Power and Current:
43 W, .4 A @ 120 V, 60 Hz
47 W, .2 A @ 230 V, 50 Hz

Weight: 3.8 lb (1.8 kg)

Size: 117 x 117 x 166.5 mm

Approvals: CE, FCC

Optional Controllers: IRC-6
