CHAUVET PROFESSIONAL Ovation F-915VW

SPECIFICATIONS

OPTICAL

• Light Source: 89 LEDs (6 red, 15 orange-red, 8 green, 12 blue, 16 royal blue, 32 lime) 3 W, (960 mA), 50,000 hours life expectancy
• Color Temperature (range): 2800 to 8000 K
• CRI: 88-92
• Beam Angle: 17° to 54°
• Field Angle: 30° to 85°
• Zoom Range: 17° to 85°
• Lumens (30°): 4,143
• Lumens (85°): 6,792
• Illuminance (30°): 1,748 lux @ 5 m
• Illuminance (85°): 414 lux @ 5 m
• Selectable PWM: 600 Hz, 1200 Hz, 2000 Hz, 4000 Hz, 6000 Hz, 25,000 Hz

DYNAMIC EFFECTS

• Dimmer: Electronic
• Zoom: Motorized
• Strobe Rate: 0 to 27 Hz
• Standalone Color Mixing: Yes
• Color Temperature Presets: Yes
• Dim Modes: 4
• Built-in Automated Programs: No

CONSTRUCTION / PHYSICAL

• Dimensions: 22.41 x 12.59 x 10.82in (569.44 x 320 x 275 mm)
• Weight: 18.6 lb (8.5 kg)
• Exterior Color: Black
• Housing Material: Aluminum alloy, Aluminum die-cast

CONNECTIONS

• Power Connection: Edison (Local) plug to Neutrik powerCON
• Power Input: Neutrik® powerCON®
• Power Output: Neutrik® powerCON®
• Data Connectors: 3- and 5-pin XLR
• Cable Length (power): 5 ft (1.5 m)

CONTROL

• Control Protocol: DMX, RDM
• DMX Channels: 1, 4, 6, 7, 9, 13, 16 or 18
• Modes/Personalities: 8 personalities (1, 4, 6, 7, 9, 13, 16, 18)

ELECTRICAL

• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power Linking: 7 units @ 120 V; 13 units @ 208 V; 14 units @ 230 V
• Power and Current: 216 W, 1.8 A @ 120 V, 60 Hz [7 A inrush]
• Power and Current: 220 W, 1.1 A @ 208 V, 60 Hz [7 A inrush]
• Power and Current: 223 W, 1 A @ 230 V, 50 Hz [7.8 A inrush]
• Power and Current (resting): 6 W, 0.050 A @ 120 V, 60 Hz
• Power and Current (resting): 11 W, 0.054 A @ 208 V, 60 Hz
• Power and Current (resting): 9 W, 0.036 A @ 230 V, 50 Hz

CERTIFICATIONS / QUALIFICATIONS

• CE, MET, FCC
• IP Rating: IP20, dry location
• Temperature (startup): -4 °F to 113 °F (-20 °C to 45 °C)
• Temperature (operating): -22 °F to 113 °F (-30 °C to 45 °C)

WHAT'S INCLUDED

• Ovation F-915VW
• Neutrik® powerCON® power cord
• Gel frame (7.5 in/191 mm accessories)

OPTIONAL ACCESSORIES

• Professional Clamps: CTC-50HC, CTC-50HCN
• Neutrik® powerCON® cables
• 3-pin or 5-pin DMX Cables
• Color Blending Filters: DF60X1D, DF20D
• Ovation F 7.5” Barndoor V2
